Looking for a display for a recreational vehicle, a car, a speedboat or an ATV?
OLED Products
| Picture | Size | Part Number | Panel Size | Resolution | Color | Thickness | Bonding | IC | Interface | Connection Method | Datasheet |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
0.8" | USMP-P008-096032WBI-A0 | 28.5 x 11.5 | 96 x 32 | W | 1.22 | COG | SSD1307 | SPI, I2C | Hot Bar |
 |
 |
0.91" | USMP-P010-128032WBI-A0 | 30 x 11.5 | 128 x 32 | W | 1.02 | COG | SSD1307 | SPI, I2C | Connector |
|
 |
0.96" | USMP-P010-128064WBI-C0 | 26.7 x 19.26 | 128 x 64 | W | 1.22 | COG | SSD1306ZBZ | Parallel, SPI, I2C | Hot Bar |
|
 |
3.2" | USMP-P032-256064WBI-A0 | 87.4 x 28.5 | 256 x 64 | W | 2.01 | COF | SSD1322 | Parallel, SPI | Connector |
|
TFT Products
| Diagonal Size | Resolution | Part Number | Interface | Active Area | Viewing Angle | Contrast Ratio | Brightness | Operating Temp. | Touch Panel | Datasheet |
|---|---|---|---|---|---|---|---|---|---|---|
| 1.1" | 132*132 | USMP-T011-013013MDV-A0 | MIPI-SPI | 19.1268 x 19.1268 | 85 / 85 / 85 / 85 | 800 | 1000 | -30°~80° | No |
|
| 1.26" | 320*320 | USMP-T013-032032NDH-A0 | MIPI-SPI | 31.968 × 31.968 | 55 / 80 / 45 / 55 | 150 | 300 | -20°~70° | No |
|
| 1.38" | 220*220 | USMP-T014-022022NDH-A0 | MCU | 35.10 x 35.10 | 80 / 55 / 80 / 80 | 700 | 340 | -20°~70° | No |
|
| 2.4" | 240*320 | USMP-T024-024032MEG-A1 | RGB | 36.72 x 48.96 | 90 / 90 / 90 / 90 | 500 | 400 | -20~70° | No |
|
| 2.4" | 240*320 | USMP-LPS-T024-024032MFW-B0 | MCU | 80 / 80 / 80 / 80 | 1200 | 350 | -20~70° | Yes |
|
|
| 2.47" | 480*480 | USMP-T025-480x480-19100360 | MIPI-SPI | 62.64 x 62.64 | 85 / 85 / 85 / 85 | 1000 | 400 | -10°~60° | No |
|
| 2.95" | 432*432 | USMP-T030-432432NAV-A0 | Digital 24-bits RGB | 74.39 x 74.39 | 80 / 80 / 80 / 80 | 800 | 1000 | -30º~85º | No |
|
| 2.95" | 432*432 | USMP-T030-043043NAV-B0 | Serial RGB | 74.39 x 74.39 | 80 / 80 / 80 / 80 | 800 | 1000 | -30°~85° | No |
|
| 3.0" | 432*432 | USMP-T030-043043CAV-A0 | RGB | 74.39 x 74.39 | 80 / 80 / 80 / 80 | 800 | 850 | -30°~85° | Yes |
|
| 3.5" | 240*320 | USMP-T035-024032NDU-A0 | C-MOS 50 pins | 53.28 x 71.04 | 85 / 85 / 85 / 85 | 900 | 600 | -30º~85º | No |
|
| 3.5" | 320*240 | USMP-T035-032024NAS-A0 | Digital 24-bits RGB | 70.08 x 52.56 | 45 / 50 / 50 / 50 | 200~250 | 280 | -20º~70º | No |
|
| 4.21" | 680*680 | USMP-T042-680680NAV-A0 | RGB | 106.68 x 106.68 | 80 / 80 / 80 / 80 | 1000 | -20°~70° | No |
|
|
| 4.3" | 480*272 | USMP-T043-048027NAS-A0 | Digital 24-bits RGB | 96.7 x 55.3 | 60 / 60 / 60 / 60 | 600 | 460 | -20º~70º | No |
|
| 5" | 800*480 | USMP-LPS-T050-080048MFD-A0 | RGB | 80 / 80 / 80 / 80 | 1000 | 800 | -30~80° | Yes |
|
|
| 5" | 800*480 | USMP-T050-080048NDU-A0 | C-MOS 40 pins | 108 x 64.8 | 60 / 70 / 70 / 70 | 600 | 1000 | -30º~80º | No |
|
| 5.7" | 320*240 | USMP-T057-032024NAF-A0 | RGB | 115.20 x 86.4 | 50 / 65 / 65 / 65 | 450 | 1200 | -20°~70° | No |
|
| 5.7" | 640*480 | USMP-T057-064048NBQ-A0 | 1 ch TTL | 115.2 x 86.4 | 70 / 70 / 80 / 80 | 800 | 450 | -20°~85° | No |
|
| 5.7" | 640*480 | USMP-T057-064048NCJ-A0 | 1 ch TTL | 115.2 x 86.4 | 65 / 65 / 75 / 75 | 600 | 500 | -30°~85° | No |
|
| 5.7" | 320*240 | USMP-T057-032024NDU-A0 | RGB | 115.2 x 86.4 | 80 / 60 / 80 / 80 | 800 | 800 | -20°~70° | No |
|
| 5.7" | 640*480 | USMP-T057-064048NAV-A0 | RGB | 115.2 x 86.4 | 60 / 40 / 70 / 70 | 300 | 900 | -20°~70° | No |
|
| 5.7" | 320*240 | USMP-T057-032024NAV-A0 | RGB | 115.2 x 86.4 | 50 / 70 / 70 / 70 | 490 | 350 | -20°~70° | No |
|
| 6.5" | 640*480 | USMP-T065-064048NDN-A0 | 1 ch LVDS | 132.48 x 99.36 | 80 / 80 / 70 / 70 | 600 | 700 | -30º~85º | No |
|
| 7" | 800*480 | USMP-T070-080048RCJ-A0 | RGB | 152.4 x 91.44 | 60 / 60 / 70 / 70 | 400 | 400 | -20º~70º | Yes |
|
| 7" | 1280*768 | USMP-LPS-T070-128076MFW-A0 | LVDS | 80 / 80 / 80 / 80 | 1400 | 1300 | -30~80° | Yes |
|
|
| 7" | 800*480 | USMP-T070-080048CCJ-A0 | 6bit LVDS | 152.4 x 91.44 | 65 / 65 / 70 / 70 | 400 | 850 | -20°~70° | PCap |
|
| 7" | 800*480 | USMP-T070-080048NDN-A0 | 1 ch LVDS 8 bit | 152.4 x 91.44 | 80 / 80 / 60 / 80 | 500 | 400 | -30º~85º | No |
|
| 7" | 800*480 | USMP-VC070WV-03L-TP-2 | 6bit LVDS | 152.4 x 91.44 | 65 / 65 / 70 / 70 | 300 | 850 | -20°~70° | PCap |
|
| 7" | 800*480 | USMP-T070-080048NDU-A0 | 20-pin LVDS | 152.4 x 91.44 | 85 / 85 / 85 / 85 | 600 | 450 | -30º~80º | No |
|
| 7" | 800*480 | USMP-T070-080048NAV-A0 | RGB | 152.4 x 91.44 | 80 / 80 / 80 / 80 | 600 | 500 | -20º~70º | No |
|
| 7" | 800*480 | USMP-T070-080048NDU-B0 | 20-pin LVDS | 152.4 x 91.44 | 85 / 85 / 85 / 85 | 1000 | 800 | -40º~85º | No |
|
| 7" | 800*480 | USMP-T070-080048CAV-A0 | LVDS | 152.4 x 91.44 | 65 / 65 / 70 / 70 | 400 | 850 | -30°~80° | Yes |
|
| 7" | 1920*1080 | USMP-T070-192108NDU-A0 | 20-pin LVDS | 169 x 104 x 10 | 85 / 85 / 85 / 85 | 800 | 700 | -20º~70º | No |
|
| 8" | 800*600 | USMP-T080-080060NDU-A0 | LVDS | 174 x 104.4 | 60 / 80 / 80 / 80 | 800 | 1500 | -30º~80º | No |
|
| 8" | 1024*600 | USMP-T080-102060NBQ-A0 | LVDS | 176.6 × 99.36 | 85 / 85 / 85 / 85 | 1000 | 750 | -30º~85º | No |
|
| 8.4" | 800*600 | USMP-T084-080060NDN-A0 | 1 ch LVDS 8 bit | 170.4 x 127.8 | 80 / 80 / 80 / 60 | 600 | 450 | -30º~85º | No |
|
| 10.1" | 1024*600 | USMP-T101-102060NAS-A0 | LVDS | 222.72 x 125.28 | 80 / 80 / 80 / 80 | 500 | 500 | -30º~85º | No |
|
| 10.1" | 1280*800 | USMP-LPS-T101-128080MFD-A0 | MIPI-SPI | 80 / 80 / 80 / 80 | 1000 | 1000 | -30~80° | Yes |
|
|
| 10.1" | 1280*1200 | USMP-T101-192120NDU-A0 | LVDS | 217.44 x 135.9 | 85 / 85 / 85 / 85 | 800 | 800 | -30º~85º | No |
|
| 10.4" | 640*480 | USMP-T104-064048NDN-A0 | 1 ch TTL | 211.2 x 158.4 | 80 / 80 / 60 / 70 | 700 | 400 | -20º~80º | No |
|
| 10.4" | 800*600 | USMP-T104-080060NDU-A0 | 20-pin LVDS | 211.2 x 158.4 | 60 / 80 / 80 / 80 | 800 | 1500 | -30º~80º | No |
|
| 10.4" | 800*600 | USMP-T104-080060NCJ-A0 | 6bit LVDS | 211.2 x 158.4 | 70 / 70 / 50 / 60 | 500 | 500 | -30º~80º | No |
|
| 10.4" | 1024*768 | USMP-T104-102076NDU-A0 | 20-pin LVDS | 211.2 x 158.4 | 60 / 70 / 75 / 75 | 800 | 1200 | -20º~70º | No |
|
| 12.1" | 800*600 | USMP-T121-010076NAF-A0 | LVDS | 245.76 x 184.32 | 70 / 70 / 80 / 80 | 700 | 600 | -30º~80º | No |
|
| 12.1" | 800*600 | USMP-T121-080060NDN-A0 | 8-bit | 246 x 184.5 | 80 / 80 / 65 / 75 | 700 | 450 | -30º~85º | No |
|
| 12.3" | 1920*720 | USMP-T123-19200720C-82A1 | LVDS | 292.032×109.512 | 85 / 85 / 85 / 85 | 1000 | 1000 | -30 ~ 80° | CTP |
|
| 12.3" | 1920*720 | USMP-T123-192072NBQ-A0 | LVDS | 292.608 x 109.728 | 85 / 85 / 85 / 85 | 1000 | 750 | -30 ~ 85° | No |
|
| 12.3" | 1920*720 | USMP-T123-192072NDV-A0 | LVDS | 292.023 x 109.512 | 85 / 85 / 85 / 85 | 1000 | 700 | -30 ~ 80° | No |
|
| 12.3" | 1920*720 | USMP-T123-192072CDV-A2 | LVDS | 292.032 x 109.512 | 85 / 85 / 85 / 85 | 1000 | 1000 | -30°~80° | CTP |
|
| 19" | 1280*1024 | USMP-T190-128102NDN-A0 | 2 ch LVDS | 376.32 x 301.056 | 89 / 89 / 89 / 89 | 2000 | 600 | 0 ~ 50° | No |
|
| 22" | 1680*1050 | USMP-T220-168105NDN-A0 | 2 ch LVDS | 473.76 x 296.1 | 89 / 89 / 89 / 89 | 2000 | 250 | 0º~50º | No |
|
| 23" | 1920 x 1080 | USMP-M230HGE-P20 | 2 ch LVDS | 509.184 x 286.416 | 85 / 85 / 85 / 85 | 1000 | 0°~50° | No |
|
|
| 27" | 1920*1080 | USMP-T27-192108MEH-TBD | VGA/DVI-D/HDMI | 597.6 x 336.15 | 89 / 89 / 89 / 89 | 1000 | 1700 | -30º~80º | Yes |
|
| 28" | 3480*2160 | USMP-T280-384216NBQ-A0 | 51 pins 8 lane –V by 1 | 620.93 x 341.28 | 80 / 80 / 85 / 85 | 1000 | 300 | 0º~50º | No |
|
| 50" | 3840*2160 | USMP-T500-384216NBQ-A0 | 8 lane V by 1 | 1095.84 x 616.41 | 88 / 88 / 88 / 88 | 4000 | 500 | 0º~50º | No |
|
Open Frame Monitor Products
| Panel Size | Part Number | Resolution | Active Size | Brightness | Display Colors | Operating Temp. | Pixel Pitch | Viewing Angle | Datasheet |
|---|---|---|---|---|---|---|---|---|---|
| 7" | USMP-F070-102060RBZ-A0 | 1024 x 600 | 156.6 x 90 | 400 | 16.7M | -30º~85º | 0.150 x 0.150 | 75º / 75º / 75º / 75º |
|
| 9.7" | USMP-F097-102076CBZ-A0 | 1024 x 768 | 196.61 x 147.46 | 260 | 16.2M | 0º~50º | 0.192 x 0.192 | 85º / 85º / 85º / 85º |
|
| 10.1" | USMP-F101-128080CBZ-A0 | 1280 x 800 | 216.96 x 135.60 | 300 | 16.2M | -20º~60º | 0.1695 x 0.1695 | 85º / 85º / 85º / 85º |
|
| 10.4" | USMP-F104-102076CBZ-A0 | 1024 x 768 | 211.2 x 158.4 | 350 | 16.7M/262K | 0º~50º | 0.2055 x 0.2055 | 85º / 85º / 85º / 85º |
|
| 12.1" | USMP-F121-102076CBZ-A0 | 1024 x 768 | 245.76 x 184.32 | 350 | 16.7M | -20º~70º | 0.24 x 0.24 | 80º / 80º / 80º / 80º |
|
| 14" | USMP-F140-192108CBZ-B0 | 1920 x 1080 | 309.312 x 173.988 | 250 | 262k | 0º~50º | 0.1611 x 0.1611 | 85º / 85º / 85º / 85º |
|
| 14" | USMP-F140-192108CBZ-A0 | 1920 x 1080 | 309.312 x 173.988 | 250 | 262K | 0º~50º | 0.264 x 0.264 | 85º / 85º / 85º / 85º |
|
| 15" | USMP-F150-102076CBZ-A0 | 1024 x 768 | 304.128 x 228.096 | 250 | 16.2M/262k | -20º~70º | 0.297 x 0.297 | 80º / 80º / 70º / 70º |
|
| 15" | USMP-F150-102076RBZ-A0 | 1024 x 768 | 304.128 x 228.096 | 300 | 16.2M/262k | -10º~70º | 0.297 x 0.297 | 89º / 89º / 89º / 89º |
|
| 15" | USMP-F150-102076RBZ-B0 | 1024 x 768 | 304.128 x 228.096 | 250 | 262k | -10º~70º | 0.297 x 0.297 | 50º / 50º / 60º / 60º |
|
| 15.6" | USMP-F156-192108CBZ-A0 | 1920 x 1080 | 344.16 x 193.59 | 350 | 16.7M | -10º~70º | 0.17925 x 0.17925 | 60º / 60º / 70º / 70º |
|
| 17" | USMP-F170-128102RBZ-A0 | 1280 x 1084 | 337.92 x 270.33 | 250 | 16.7M | 0º~70º | 0.24 x 0.24 | 80º / 80º / 85º / 85º |
|
| 17" | USMP-F170-128102CBZ-A0 | 1280 x 1024 | 337.920 x 270.336 | 250 | 16.7M | -20º~60º | 0.264 x 0.264 | 85º / 85º / 80º / 80º |
|
| 17" | USMP-F170-128102CBZ-B0 | 1280 x 1024 | 337.920 x 270.336 | 350 | 16.7M | -20º~60º | 0.264 x 0.264 | 85º / 85º / 80º / 80º |
|
| 17" | USMP-F170-128102CBZ-C0 | 1280 x 1024 | 337.920 x 270.336 | 350 | 16.7M | -0º~50º | 0.264 x 0.264 | 85º / 85º / 80º / 80º |
|
| 18.5" | USMP-OFIA185-W-01C | 1366 x 768 | 409.8 x 230.4 | 250 | 16.7M | 0°~50° | 0.3 x 0.3 | 85º / 85º / 80º / 80º |
|
| 18.5" | USMP-OFIA185-W-01B | 1366 x 768 | 409.8 x 230.4 | 250 | 16.7M | 0°~50° | 0.3 x 0.3 | 85º / 85º / 80º / 80º |
|
| 18.5" | USMP-F185-192108CBZ-A0 | 1920 x 1080 | 408.96 x 230.04 | 350 | 16.7M | -20º~70º | 0.213 x 0.213 | 89º / 89º / 89º / 89º |
|
| 19" | USMP-F190-128102CBZ-A0 | 1280 x 1024 | 376.32 x 301.06 | 250 | 16.7M | -20º~50º | 0.264 x 0.264 | 85º / 85º / 80º / 80º |
|
| 21.5" | USMP-F215-192108CBZ-A0 | 1920 x 1080 | 476.64 x 268.116 | 250 | 16.7M | 0º~50º | 0.24825 x 0.24825 | 89º / 89º / 89º / 89º |
|
| 21.5" | USMP-F215-192108CBZ-C0 | 1920 x 1080 | 476.064 x 267.786 | 450 | 16.7M | 0º~50º | 0.24795 x 0.24795 | 89º / 89º / 89º / 89º |
|
| 21.5" | USMP-F215-192108CBZ-B0 | 1920 x 1080 | 476.64 x 268.116 | 250 | 16.7M | 0º~50º | 0.24825 x 0.24825 | 89º / 89º / 89º / 89º |
|
| 21.5" | USMP-F215-192108CBZ-D0 | 1920 x 1080 | 476.064 x 267.786 | 250 | 16.7M | 0º~50º | 0.24825 x 0.24825 | 89º / 89º / 89º / 89º |
|
| 31.5" | USMP-F315-192108CBZ-A0 | 1920 x 1080 | 698.4 x 392.85 | 300 | 16.7M | 0º~50º | 0.12125 x 0.12125 | 89º / 89º / 89º / 89º |
|
| 32" | USMP-F320-192108CBZ-A0 | 1920 x 1080 | 698.4 x 392.85 | 300 | 16.7M | 0º~50º | 0.12125 x 0.12125 | 89º / 89º / 89º / 89º |
|
| 43" | USMP-F430-192108CBZ-A0 | 1920 x 1080 | AMG-43IPAM01T1-en | 300 | 16.7M | 0º~50º | 89º / 89º / 89º / 89º |
|
Whether you are replacing the gagues, adding a display to a dashboard, replacing a center console, or looking to develop an aftermarket part, let the Display Engineers from US Micro Products guide you through the process of designing the best display for your project.
The following features are necessary to have a high performance display for a transportation application:
| OPTIONAL FEATURES: | |
|---|---|
| High Brightness for outdoor readability | High image quality (high resolution and high contrast) |
| Wide view angles | Resistive or Capacitive touch |
| Wide temperature range | Anti-fingerprint coating |
| Long display lifetime | Optical bonding to increase brightness, clarity, and reduce reflection |
| Long product support | Anti-scattering film and strengthen cover lens |
| Sunlight durability film | Quick response time, refresh rate to avoid lag |
| Low power consumption | |
| Low cost | |
| Ruggedized design |
| GAUGE REPLACEMENT |
|---|
| AMOLED |
| Small size TFTs |
| Segmented LCDs |
| PMOLEDs |
| Character LCDs |
| DASHBOARD REPLACEMENT |
|---|
| Wide aspect ratio TFTs |
| Small size TFTs |
| Segmented LCDs |
| AMOLEDs |
| Chemically strengthened P-Cap Solutions |
| CONSOLE REPLACEMENT |
|---|
| Standard and wide aspect ratio TFTs |
| AR and anti-fingerprint coated cover lenses |
| Customer and standard AM and PMOLEDs |
APPLICATIONS
LCD - Ford Think Electric Vehicle
Ford needed a display to show a variety of icons and read outs including battery life, mileage and more. They needed it to be circular in shape to fit the design of the dashboard. We designed a custom display to meet this requirement. The end result for Ford was a display that was legible in sunlight, and displayed their custom icons while providing a cost efficient solution.
The customer required a ruggedized display for a boat console. We designed a 12.3" TFT 1280x480 with a 1000 nits backlight for high brightness and a chemically strengthened cover lens with glass on glass P-cap sensor. Another solution we manufactured for this client was a 7" TFT 800x480, 1000 nits backlight and AR coating for the same application.
Truck Dashboard Console
An amber backlight LED was used for this application. The backlight designed to provide a robust product that can withstand a harsh environment of shock, vibration, wide temperature ranges and a long life – up to 100,000 hours.
Backlight - Automotive Console
Our customer required a robust solution with long life and multiple colors. So we designed an LED solution using several colors of LEDs and a special housing and light guide that provided clear lighting without any color distortion.
Engine Tuner for Automotive
Our 16x2 Character Display outfits an engine tuner for commercial cars and trucks. Its low profile allows it to fit in the tight size constraints of this handheld application.
Automotive TFT with Touch Screen
Our TFTs can support wide temperatures and have high brightness, as well as an integrated touch screen.
In Car Entertainment Display
Our 6.4" flat panel display is a great product for the ever-growing market of on car entertainment. Its compact footprint makes it ideal for mounting in seats, dash or over-head applications.
Our Display Engineers will analyze your requirements and design the best solution for your specific application. Once we design a solution, we will manufacture, do quality control and deliver a high quality display at the best value. To find out more about our Engineered Display Solutions Process, visit our Custom Displays page
