Consumer Applications
You are here
Specializing in display technologies, we have provided many cost effective solutions for high volume applications.
OLED Products
Picture | Size | Part Number | Panel Size | Resolution | Color | Thickness | Bonding | IC | Interface | Connection Method | Datasheet |
---|---|---|---|---|---|---|---|---|---|---|---|
![]() |
0.49" | USMP-P005-064032WBI-A0 | 14.5 x 11.6 | 64 x 32 | W | 1.02 | COG | SSD1306ZBZ | I2C | Hot Bar |
![]() |
![]() |
0.7" | USMP-P32401 | 24 x 7.44 | 96 x 16 | W | 1.02 | COG | LD7054 | Parallel, SPI, I2C | Connector |
![]() |
![]() |
0.7" | USMP-P007-096016WBI-A0 | 24 x 7.44 | 96 x 16 | W | 1.02 | COG | LD7054 | Parallel, SPI, I2C | Connector |
![]() |
![]() |
0.8" | USMP-P008-096032WBI-A0 | 28.5 x 11.5 | 96 x 32 | W | 1.22 | COG | SSD1307 | SPI, I2C | Hot Bar |
![]() |
![]() |
0.91" | USMP-P010-128032WBI-A0 | 30 x 11.5 | 128 x 32 | W | 1.02 | COG | SSD1307 | SPI, I2C | Connector |
![]() |
![]() |
0.96" | USMP-P010-128064WBI-C0 | 26.7 x 19.26 | 128 x 64 | W | 1.22 | COG | SSD1306ZBZ | Parallel, SPI, I2C | Hot Bar |
![]() |
![]() |
0.96" | USMP-P25317 | 26.7 x 19.26 | 128 x 64 | W | 1.22 | COG | SSD1306ZBZ | Parallel, SPI, I2C | Hot Bar |
![]() |
![]() |
1.1" | USMP-P19602 | 29 x 21 | 96 x 64 | Y | 1.61 | TAB | SSD1325 | Parallel, SPI, I2C | Hot Bar |
![]() |
![]() |
1.1" | USMP-P19603 | 29 x 21 | 96 x 64 | W | 1.42 | TAB | SSD1325 | Parallel, SPI, I2C | Connector |
![]() |
![]() |
1.1" | USMP-P19605 | 29 x 21 | 96 x 64 | Y | 1.61 | TAB | SSD1325 | Parallel, SPI, I2C | Connector |
![]() |
![]() |
1.12" | USMP-P27801-A | 25.8 x 30.1 | 96 x 96 | 65k, 262k | 1.2227 | COG | SSD1351 | Parallel, SPI | Hot Bar |
![]() |
![]() |
1.27" | USMP-P013-052160MBI-A0 | 14 x 38.5 | 52 x 160 | 262k | 1.02 | COG | SSD1357Z | SPI | Connector |
![]() |
![]() |
1.29" | USMP-P013-128096LBI-A0 | 33 x 25.8 | 128 x 96 | 65k, 262k | 1.02 | COF | SSD1351UR1 | Parallel, SPI | Hot Bar |
![]() |
![]() |
1.32" | USMP-P013-128096WBI-A0 | 32.5 x 29.2 | 128 x 96 | W | 1.42 | COG | SSD1307 | Parallel, SPI, I2C | Hot Bar |
![]() |
![]() |
1.46" | USMP-P23903 | 33.5 x 33.5 | 128 x 128 | 65k, 262k | 1.42 | COF | SSD1351 | Parallel, SPI | Connector |
![]() ![]() |
![]() |
1.46" | USMP-P015-128128LBI-B0 | 33.5 x 33.5 | 128 x 128 | 65k, 262k | 1.42 | COF | SSD1351 | Parallel, SPI | Connector |
![]() |
![]() |
1.5" | USMP-P015-128128WBI-A0 | 33.8 x 36.5 | 128 x 128 | W | 1.22 | COG | SSD1327 | Parallel, SPI, I2C | Hot Bar |
![]() |
![]() |
1.6" | USMP-P22403 | 41.9 x 25.3 | 128 x 64 | Y | 1.42 | TAB | SSD1325 | Parallel, SPI, I2C | Connector |
![]() |
![]() |
1.6" | USMP-P016-128064YBI-A0 | 41.9 x 28 | 128 x 64 | Y | 1.42 | COF | SSD1325 | Parallel, SPI | Connector |
![]() |
![]() |
1.6" | USMP-P22401 | 41.9 x 25.3 | 128 x 64 | Y | 1.61 | TAB | SSD1325 | Parallel, SPI, I2C | Connector |
![]() |
![]() |
1.6" | USMP-P22402 | 41.9 x 25.3 | 128 x 64 | Y | 1.42 | TAB | SSD1325 | Parallel, SPI, I2C | Connector |
![]() |
![]() |
1.8" | USMP-P018-160128LBI-A0 | 42.7 x 33.4 | 160 x 128 | 65k, 262k | 1.85 | COF | SSD1353 | Parallel, SPI | Hot Bar |
![]() |
![]() |
2.4" | USMP-P024-128022YBI-A0 | 63.3 x 20.8 | 128 x 22 | Y | 1.42 | COG | SSD1305 | Parallel, SPI, I2C | Hot Bar |
![]() |
![]() |
2.4" | USMP-P024-128064WBI-B0 | 60.5 x 37 | 128 x 64 | W | 1.82 | COG | SSD0301 | Parallel, SPI, I2C | Connector |
![]() |
![]() |
3.2" | USMP-P032-256064YBI-A0 | 87.4 x 28.5 | 256 x 64 | Y | 1.82 | COF | SSD1322 | Parallel, SPI | Connector |
![]() |
![]() |
3.2" | USMP-P032-256064WBI-A0 | 87.4 x 28.5 | 256 x 64 | W | 2.01 | COF | SSD1322 | Parallel, SPI | Connector |
![]() |
TFT Products
Diagonal Size | Resolution | Part Number | Interface | Active Area | Viewing Angle | Contrast Ratio | Brightness | Operating Temp. | Touch Panel | Datasheet |
---|---|---|---|---|---|---|---|---|---|---|
1.1" | 132*132 | USMP-T011-013013MDV-A0 | MIPI-SPI | 19.1268 x 19.1268 | 85 / 85 / 85 / 85 | 800 | 1000 | -30°~80° | No |
![]() |
1.26" | 320*320 | USMP-T013-032032NDH-A0 | MIPI-SPI | 31.968 × 31.968 | 55 / 80 / 45 / 55 | 150 | 300 | -20°~70° | No |
![]() |
1.38" | 220*220 | USMP-T014-022022NDH-A0 | MCU | 35.10 x 35.10 | 80 / 55 / 80 / 80 | 700 | 340 | -20°~70° | No |
![]() |
1.77" | 128*160 | USMP-T018-012016NAS-A0 | 8-bit | 28.032 x 35.04 | 45 / 15 / 45 / 45 | 150~200 | 290 | -20º~70º | No |
![]() |
2.2" | 240*320 | USMP-T022-024032NCJ-A0 | MPU | 38.48 x 44.64 | 80 / 80 / 80 / 80 | 300~700 | 400 | -20º~70º | No |
![]() |
2.4" | 240*320 | USMP-T024-024032MEG-A1 | RGB | 36.72 x 48.96 | 90 / 90 / 90 / 90 | 500 | 400 | -20~70° | No |
![]() |
2.4" | 240*320 | USMP-LPS-T024-024032MFW-B0 | MCU | 80 / 80 / 80 / 80 | 1200 | 350 | -20~70° | Yes |
![]() |
|
2.47" | 480*480 | USMP-T025-480x480-19100360 | MIPI-SPI | 62.64 x 62.64 | 85 / 85 / 85 / 85 | 1000 | 400 | -10°~60° | No |
![]() |
2.95" | 432*432 | USMP-T030-043043NAV-B0 | Serial RGB | 74.39 x 74.39 | 80 / 80 / 80 / 80 | 800 | 1000 | -30°~85° | No |
![]() |
3.0" | 432*432 | USMP-T030-043043CAV-A0 | RGB | 74.39 x 74.39 | 80 / 80 / 80 / 80 | 800 | 850 | -30°~85° | Yes |
![]() |
3.5" | 320*240 | USMP-T035-032024NAS-A0 | Digital 24-bits RGB | 70.08 x 52.56 | 45 / 50 / 50 / 50 | 200~250 | 280 | -20º~70º | No |
![]() |
3.5" | 240*320 | USMP-T035-024032NDU-A0 | C-MOS 50 pins | 53.28 x 71.04 | 85 / 85 / 85 / 85 | 900 | 600 | -30º~85º | No |
![]() |
4.21" | 680*680 | USMP-T042-680680NAV-A0 | RGB | 106.68 x 106.68 | 80 / 80 / 80 / 80 | 1000 | -20°~70° | No |
![]() |
|
4.3" | 480*272 | USMP-T043-048027NAS-A0 | Digital 24-bits RGB | 96.7 x 55.3 | 60 / 60 / 60 / 60 | 600 | 460 | -20º~70º | No |
![]() |
5" | 800*480 | USMP-T050-080048NDU-A0 | C-MOS 40 pins | 108 x 64.8 | 60 / 70 / 70 / 70 | 600 | 1000 | -30º~80º | No |
![]() |
5" | 800*480 | USMP-LPS-T050-080048MFD-A0 | RGB | 80 / 80 / 80 / 80 | 1000 | 800 | -30~80° | Yes |
![]() |
|
5.7" | 640*480 | USMP-T057-064048NCJ-A0 | 1 ch TTL | 115.2 x 86.4 | 65 / 65 / 75 / 75 | 600 | 500 | -30°~85° | No |
![]() |
5.7" | 640*480 | USMP-T057-064048NAV-A0 | RGB | 115.2 x 86.4 | 60 / 40 / 70 / 70 | 300 | 900 | -20°~70° | No |
![]() |
5.7" | 320*240 | USMP-T057-032024NAV-A0 | RGB | 115.2 x 86.4 | 50 / 70 / 70 / 70 | 490 | 350 | -20°~70° | No |
![]() |
5.7" | 320*240 | USMP-T057-032024NAF-A0 | RGB | 115.20 x 86.4 | 50 / 65 / 65 / 65 | 450 | 1200 | -20°~70° | No |
![]() |
5.7" | 320*240 | USMP-T057-032024NDU-A0 | RGB | 115.2 x 86.4 | 80 / 60 / 80 / 80 | 800 | 800 | -20°~70° | No |
![]() |
5.7" | 640*480 | USMP-T057-064048NBQ-A0 | 1 ch TTL | 115.2 x 86.4 | 70 / 70 / 80 / 80 | 800 | 450 | -20°~85° | No |
![]() |
6.5" | 640*480 | USMP-T065-064048NDN-A0 | 1 ch LVDS | 132.48 x 99.36 | 80 / 80 / 70 / 70 | 600 | 700 | -30º~85º | No |
![]() |
7" | 1280*768 | USMP-LPS-T070-128076MFW-A0 | LVDS | 80 / 80 / 80 / 80 | 1400 | 1300 | -30~80° | Yes |
![]() |
|
7" | 800*480 | USMP-T070-080048NAV-A0 | RGB | 152.4 x 91.44 | 80 / 80 / 80 / 80 | 600 | 500 | -20º~70º | No |
![]() |
7" | 800*480 | USMP-T070-080048CCJ-A0 | 6bit LVDS | 152.4 x 91.44 | 65 / 65 / 70 / 70 | 400 | 850 | -20°~70° | PCap |
![]() |
7" | 800*480 | USMP-T070-080048NDU-B0 | 20-pin LVDS | 152.4 x 91.44 | 85 / 85 / 85 / 85 | 1000 | 800 | -40º~85º | No |
![]() |
7" | 800*480 | USMP-VC070WV-03L-TP-2 | 6bit LVDS | 152.4 x 91.44 | 65 / 65 / 70 / 70 | 300 | 850 | -20°~70° | PCap |
![]() |
7" | 1920*1080 | USMP-T070-192108NDU-A0 | 20-pin LVDS | 169 x 104 x 10 | 85 / 85 / 85 / 85 | 800 | 700 | -20º~70º | No |
![]() |
7" | 800*480 | USMP-T070-080048RCJ-A0 | RGB | 152.4 x 91.44 | 60 / 60 / 70 / 70 | 400 | 400 | -20º~70º | Yes |
![]() |
7" | 800*480 | USMP-T070-080048CAV-A0 | LVDS | 152.4 x 91.44 | 65 / 65 / 70 / 70 | 400 | 850 | -30°~80° | Yes |
![]() |
7" | 800*480 | USMP-T070-080048NDN-A0 | 1 ch LVDS 8 bit | 152.4 x 91.44 | 80 / 80 / 60 / 80 | 500 | 400 | -30º~85º | No |
![]() |
7" | 800*480 | USMP-T070-080048NDU-A0 | 20-pin LVDS | 152.4 x 91.44 | 85 / 85 / 85 / 85 | 600 | 450 | -30º~80º | No |
![]() |
8" | 1024*600 | USMP-T080-102060NBQ-A0 | LVDS | 176.6 × 99.36 | 85 / 85 / 85 / 85 | 1000 | 750 | -30º~85º | No |
![]() |
8" | 800*600 | USMP-T080-080060NDU-A0 | LVDS | 174 x 104.4 | 60 / 80 / 80 / 80 | 800 | 1500 | -30º~80º | No |
![]() |
8.4" | 800*600 | USMP-T084-080060NDN-A0 | 1 ch LVDS 8 bit | 170.4 x 127.8 | 80 / 80 / 80 / 60 | 600 | 450 | -30º~85º | No |
![]() |
10.1" | 1280*1200 | USMP-T101-192120NDU-A0 | LVDS | 217.44 x 135.9 | 85 / 85 / 85 / 85 | 800 | 800 | -30º~85º | No |
![]() |
10.1" | 1280*800 | USMP-LPS-T101-128080MFD-A0 | MIPI-SPI | 80 / 80 / 80 / 80 | 1000 | 1000 | -30~80° | Yes |
![]() |
|
10.1" | 1024*600 | USMP-T101-102060NAS-A0 | LVDS | 222.72 x 125.28 | 80 / 80 / 80 / 80 | 500 | 500 | -30º~85º | No |
![]() |
10.4" | 800*600 | USMP-T104-080060NDU-A0 | 20-pin LVDS | 211.2 x 158.4 | 60 / 80 / 80 / 80 | 800 | 1500 | -30º~80º | No |
![]() |
12.1" | 800*600 | USMP-T121-010076NAF-A0 | LVDS | 245.76 x 184.32 | 70 / 70 / 80 / 80 | 700 | 600 | -30º~80º | No |
![]() |
12.1" | 800*600 | USMP-T121-080060NDN-A0 | 8-bit | 246 x 184.5 | 80 / 80 / 65 / 75 | 700 | 450 | -30º~85º | No |
![]() |
12.3" | 1920*720 | USMP-T123-19200720C-82A1 | LVDS | 292.032×109.512 | 85 / 85 / 85 / 85 | 1000 | 1000 | -30 ~ 80° | CTP |
![]() |
12.3" | 1920*720 | USMP-T123-192072NBQ-A0 | LVDS | 292.608 x 109.728 | 85 / 85 / 85 / 85 | 1000 | 750 | -30 ~ 85° | No |
![]() |
12.3" | 1920*720 | USMP-T123-192072NDV-A0 | LVDS | 292.023 x 109.512 | 85 / 85 / 85 / 85 | 1000 | 700 | -30 ~ 80° | No |
![]() |
12.3" | 1920*720 | USMP-T123-192072CDV-A2 | LVDS | 292.032 x 109.512 | 85 / 85 / 85 / 85 | 1000 | 1000 | -30°~80° | CTP |
![]() |
19" | 1280*1024 | USMP-T190-128102NDN-A0 | 2 ch LVDS | 376.32 x 301.056 | 89 / 89 / 89 / 89 | 2000 | 600 | 0 ~ 50° | No |
![]() |
22" | 1680*1050 | USMP-T220-168105NDN-A0 | 2 ch LVDS | 473.76 x 296.1 | 89 / 89 / 89 / 89 | 2000 | 250 | 0º~50º | No |
![]() |
23" | 1920 x 1080 | USMP-M230HGE-P20 | 2 ch LVDS | 509.184 x 286.416 | 85 / 85 / 85 / 85 | 1000 | 0°~50° | No |
![]() |
|
27" | 1920*1080 | USMP-T27-192108MEH-TBD | VGA/DVI-D/HDMI | 597.6 x 336.15 | 89 / 89 / 89 / 89 | 1000 | 1700 | -30º~80º | Yes |
![]() |
28" | 3480*2160 | USMP-T280-384216NBQ-A0 | 51 pins 8 lane –V by 1 | 620.93 x 341.28 | 80 / 80 / 85 / 85 | 1000 | 300 | 0º~50º | No |
![]() |
50" | 3840*2160 | USMP-T500-384216NBQ-A0 | 8 lane V by 1 | 1095.84 x 616.41 | 88 / 88 / 88 / 88 | 4000 | 500 | 0º~50º | No |
![]() |
By developing very efficient designs, we can save in both component cost and in power consumption.
OPTIONAL FEATURES: | |
---|---|
High image quality (high resolution and high contrast) | High color gamut |
Wide view angle | High brightness, outdoor readability |
Quick response time, quick refresh rate, 120 Mhz or higher | Ruggedized design |
Low power consumption | Wide temperature range |
Low cost |
APPLICATIONS
US Micro Products’ displays have been used for the following applications, among many others:
Technical Diving Computer
Our OLED displays are ideal for SCUBA diving equipment. The most noticeable feature on this SCUBA camera is the brightness and viewing angles made possible when compared to a standard LCD. Unlike a LCD, an OLED display can be read from any angle and any environment. Even if the light changes, the OLED display brightness can be adjusted while underwater.
Blender
Our OLED displays and passive LCDs are great options for blenders. Also, touch can be integrated. For our customer, we chose a STND white on blue display with custom pin headers and mounting hardware.
Electronic Cigarette
We used a 0.5" custom OLED with high brightness material for better sunlight readability.
Portable Game
Our customer was using a standard yellow green character display and wanted to revamp and revitalize their product. We provided them with a blue display with green characters as an alternative solution. The result is an updated look at a minimal price increase.
Telephone
A 40 x 2 standard character display was replaced by a blue display with white LEDs. By increasing the number of LEDs, we were able to provide a brighter display, therefore improving the look of the customer’s product.
Copying Machine
With a custom designed backlight, we provided a very uniform and brightly lit backlight. This high volume application was very cost sensitive. By utilizing inexpensive yellow-green LEDs and an efficient light guide, we provided the customer with a display solution that met their needs.
LED - Copier
With a custom designed backlight, we provided a very uniform and brightly lit backlight. This high volume application was very cost sensitive. By utilizing inexpensive yellow-green LEDs and an efficient light guide, we provided the customer with a solution that met their needs.
Our Display Engineers will analyze your requirements and design the best solution for your specific application. Once we design a solution, we will manufacture, do quality control and deliver a high quality display at the best value. To find out more about our Engineered Display Solutions Process, visit our Custom Displays page.
