Bigger. Bolder. Better.
OLED Products
| Picture | Size | Part Number | Panel Size | Resolution | Color | Thickness | Bonding | IC | Interface | Connection Method | Datasheet |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
0.49" | USMP-P005-064032WBI-A0 | 14.5 x 11.6 | 64 x 32 | W | 1.02 | COG | SSD1306ZBZ | I2C | Hot Bar |
 |
 |
0.7" | USMP-P007-096016WBI-A0 | 24 x 7.44 | 96 x 16 | W | 1.02 | COG | LD7054 | Parallel, SPI, I2C | Connector |
|
 |
0.8" | USMP-P008-096032WBI-A0 | 28.5 x 11.5 | 96 x 32 | W | 1.22 | COG | SSD1307 | SPI, I2C | Hot Bar |
|
 |
0.91" | USMP-P010-128032WBI-A0 | 30 x 11.5 | 128 x 32 | W | 1.02 | COG | SSD1307 | SPI, I2C | Connector |
|
 |
0.96" | USMP-P010-128064WBI-C0 | 26.7 x 19.26 | 128 x 64 | W | 1.22 | COG | SSD1306ZBZ | Parallel, SPI, I2C | Hot Bar |
|
 |
1.1" | USMP-P19602 | 29 x 21 | 96 x 64 | Y | 1.61 | TAB | SSD1325 | Parallel, SPI, I2C | Hot Bar |
|
 |
1.1" | USMP-P19603 | 29 x 21 | 96 x 64 | W | 1.42 | TAB | SSD1325 | Parallel, SPI, I2C | Connector |
|
 |
1.1" | USMP-P19605 | 29 x 21 | 96 x 64 | Y | 1.61 | TAB | SSD1325 | Parallel, SPI, I2C | Connector |
|
 |
1.1" | USMP-P19601 | 29 x 21 | 96 x 64 | Y | 1.61 | TAB | SSD1325 | Parallel, SPI | Hot Bar |
|
 |
1.27" | USMP-P013-052160MBI-A0 | 14 x 38.5 | 52 x 160 | 262k | 1.02 | COG | SSD1357Z | SPI | Connector |
|
 |
1.29" | USMP-P013-128096LBI-A0 | 33 x 25.8 | 128 x 96 | 65k, 262k | 1.02 | COF | SSD1351UR1 | Parallel, SPI | Hot Bar |
|
 |
1.32" | USMP-P013-128096WBI-A0 | 32.5 x 29.2 | 128 x 96 | W | 1.42 | COG | SSD1307 | Parallel, SPI, I2C | Hot Bar |
|
 |
1.46" | USMP-P015-128128LBI-B0 | 33.5 x 33.5 | 128 x 128 | 65k, 262k | 1.42 | COF | SSD1351 | Parallel, SPI | Connector |
|
 |
1.46" | USMP-P23903 | 33.5 x 33.5 | 128 x 128 | 65k, 262k | 1.42 | COF | SSD1351 | Parallel, SPI | Connector |
|
 |
1.5" | USMP-P015-128128WBI-A0 | 33.8 x 36.5 | 128 x 128 | W | 1.22 | COG | SSD1327 | Parallel, SPI, I2C | Hot Bar |
|
 |
1.6" | USMP-P22402 | 41.9 x 25.3 | 128 x 64 | Y | 1.42 | TAB | SSD1325 | Parallel, SPI, I2C | Connector |
|
 |
1.6" | USMP-P22403 | 41.9 x 25.3 | 128 x 64 | Y | 1.42 | TAB | SSD1325 | Parallel, SPI, I2C | Connector |
|
 |
1.6" | USMP-P016-128064YBI-A0 | 41.9 x 28 | 128 x 64 | Y | 1.42 | COF | SSD1325 | Parallel, SPI | Connector |
|
 |
1.6" | USMP-P22401 | 41.9 x 25.3 | 128 x 64 | Y | 1.61 | TAB | SSD1325 | Parallel, SPI, I2C | Connector |
|
 |
1.8" | USMP-P018-160128LBI-A0 | 42.7 x 33.4 | 160 x 128 | 65k, 262k | 1.85 | COF | SSD1353 | Parallel, SPI | Hot Bar |
|
 |
2.4" | USMP-P024-128022YBI-A0 | 63.3 x 20.8 | 128 x 22 | Y | 1.42 | COG | SSD1305 | Parallel, SPI, I2C | Hot Bar |
|
 |
2.4" | USMP-P024-128064WBI-B0 | 60.5 x 37 | 128 x 64 | W | 1.82 | COG | SSD0301 | Parallel, SPI, I2C | Connector |
|
 |
3.2" | USMP-P032-256064YBI-A0 | 87.4 x 28.5 | 256 x 64 | Y | 1.82 | COF | SSD1322 | Parallel, SPI | Connector |
|
 |
3.2" | USMP-P032-256064WBI-A0 | 87.4 x 28.5 | 256 x 64 | W | 2.01 | COF | SSD1322 | Parallel, SPI | Connector |
|
TFT Products
| Diagonal Size | Resolution | Part Number | Interface | Active Area | Viewing Angle | Contrast Ratio | Brightness | Operating Temp. | Touch Panel | Datasheet |
|---|---|---|---|---|---|---|---|---|---|---|
| 1.1" | 132*132 | USMP-T011-013013MDV-A0 | MIPI-SPI | 19.1268 x 19.1268 | 85 / 85 / 85 / 85 | 800 | 1000 | -30°~80° | No |
|
| 1.26" | 320*320 | USMP-T013-032032NDH-A0 | MIPI-SPI | 31.968 × 31.968 | 55 / 80 / 45 / 55 | 150 | 300 | -20°~70° | No |
|
| 1.38" | 220*220 | USMP-T014-022022NDH-A0 | MCU | 35.10 x 35.10 | 80 / 55 / 80 / 80 | 700 | 340 | -20°~70° | No |
|
| 1.77" | 128*160 | USMP-T018-012016NAS-A0 | 8-bit | 28.032 x 35.04 | 45 / 15 / 45 / 45 | 150~200 | 290 | -20º~70º | No |
|
| 2.2" | 240*320 | USMP-T022-024032NCJ-A0 | MPU | 38.48 x 44.64 | 80 / 80 / 80 / 80 | 300~700 | 400 | -20º~70º | No |
|
| 2.4" | 240*320 | USMP-T024-024032MEG-A1 | RGB | 36.72 x 48.96 | 90 / 90 / 90 / 90 | 500 | 400 | -20~70° | No |
|
| 2.47" | 480*480 | USMP-T025-480x480-19100360 | MIPI-SPI | 62.64 x 62.64 | 85 / 85 / 85 / 85 | 1000 | 400 | -10°~60° | No |
|
| 2.95" | 432*432 | USMP-T030-432432NAV-A0 | Digital 24-bits RGB | 74.39 x 74.39 | 80 / 80 / 80 / 80 | 800 | 1000 | -30º~85º | No |
|
| 2.95" | 432*432 | USMP-T030-043043NAV-B0 | Serial RGB | 74.39 x 74.39 | 80 / 80 / 80 / 80 | 800 | 1000 | -30°~85° | No |
|
| 3.0" | 432*432 | USMP-T030-043043CAV-A0 | RGB | 74.39 x 74.39 | 80 / 80 / 80 / 80 | 800 | 850 | -30°~85° | Yes |
|
| 3.5" | 320*240 | USMP-T035-032024NAS-A0 | Digital 24-bits RGB | 70.08 x 52.56 | 45 / 50 / 50 / 50 | 200~250 | 280 | -20º~70º | No |
|
| 3.5" | 240*320 | USMP-T035-024032NDU-A0 | C-MOS 50 pins | 53.28 x 71.04 | 85 / 85 / 85 / 85 | 900 | 600 | -30º~85º | No |
|
| 4.21" | 680*680 | USMP-T042-680680NAV-A0 | RGB | 106.68 x 106.68 | 80 / 80 / 80 / 80 | 1000 | -20°~70° | No |
|
|
| 4.3" | 480*272 | USMP-T043-048027NAS-A0 | Digital 24-bits RGB | 96.7 x 55.3 | 60 / 60 / 60 / 60 | 600 | 460 | -20º~70º | No |
|
| 5" | 800*480 | USMP-T050-080048NDU-A0 | C-MOS 40 pins | 108 x 64.8 | 60 / 70 / 70 / 70 | 600 | 1000 | -30º~80º | No |
|
| 5.7" | 640*480 | USMP-T057-064048NCJ-A0 | 1 ch TTL | 115.2 x 86.4 | 65 / 65 / 75 / 75 | 600 | 500 | -30°~85° | No |
|
| 5.7" | 640*480 | USMP-T057-064048NAV-A0 | RGB | 115.2 x 86.4 | 60 / 40 / 70 / 70 | 300 | 900 | -20°~70° | No |
|
| 5.7" | 320*240 | USMP-T057-032024NAV-A0 | RGB | 115.2 x 86.4 | 50 / 70 / 70 / 70 | 490 | 350 | -20°~70° | No |
|
| 5.7" | 320*240 | USMP-T057-032024NAF-A0 | RGB | 115.20 x 86.4 | 50 / 65 / 65 / 65 | 450 | 1200 | -20°~70° | No |
|
| 5.7" | 320*240 | USMP-T057-032024NDU-A0 | RGB | 115.2 x 86.4 | 80 / 60 / 80 / 80 | 800 | 800 | -20°~70° | No |
|
| 5.7" | 640*480 | USMP-T057-064048NBQ-A0 | 1 ch TTL | 115.2 x 86.4 | 70 / 70 / 80 / 80 | 800 | 450 | -20°~85° | No |
|
| 6.5" | 640*480 | USMP-T065-064048NDN-A0 | 1 ch LVDS | 132.48 x 99.36 | 80 / 80 / 70 / 70 | 600 | 700 | -30º~85º | No |
|
| 7" | 800*480 | USMP-VC070WV-03L-TP-2 | 6bit LVDS | 152.4 x 91.44 | 65 / 65 / 70 / 70 | 300 | 850 | -20°~70° | PCap |
|
| 7" | 800*480 | USMP-T070-080048NDU-A0 | 20-pin LVDS | 152.4 x 91.44 | 85 / 85 / 85 / 85 | 600 | 450 | -30º~80º | No |
|
| 7" | 800*480 | USMP-T070-080048NAV-A0 | RGB | 152.4 x 91.44 | 80 / 80 / 80 / 80 | 600 | 500 | -20º~70º | No |
|
| 7" | 800*480 | USMP-T070-080048NDU-B0 | 20-pin LVDS | 152.4 x 91.44 | 85 / 85 / 85 / 85 | 1000 | 800 | -40º~85º | No |
|
| 7" | 800*480 | USMP-T070-080048CAV-A0 | LVDS | 152.4 x 91.44 | 65 / 65 / 70 / 70 | 400 | 850 | -30°~80° | Yes |
|
| 7" | 1920*1080 | USMP-T070-192108NDU-A0 | 20-pin LVDS | 169 x 104 x 10 | 85 / 85 / 85 / 85 | 800 | 700 | -20º~70º | No |
|
| 7" | 800*480 | USMP-T070-080048RCJ-A0 | RGB | 152.4 x 91.44 | 60 / 60 / 70 / 70 | 400 | 400 | -20º~70º | Yes |
|
| 7" | 800*480 | USMP-T070-080048CCJ-A0 | 6bit LVDS | 152.4 x 91.44 | 65 / 65 / 70 / 70 | 400 | 850 | -20°~70° | PCap |
|
| 7" | 800*480 | USMP-T070-080048NDN-A0 | 1 ch LVDS 8 bit | 152.4 x 91.44 | 80 / 80 / 60 / 80 | 500 | 400 | -30º~85º | No |
|
| 8" | 1024*600 | USMP-T080-102060NBQ-A0 | LVDS | 176.6 × 99.36 | 85 / 85 / 85 / 85 | 1000 | 750 | -30º~85º | No |
|
| 8" | 800*600 | USMP-T080-080060NDU-A0 | LVDS | 174 x 104.4 | 60 / 80 / 80 / 80 | 800 | 1500 | -30º~80º | No |
|
| 8.4" | 800*600 | USMP-T084-080060NDN-A0 | 1 ch LVDS 8 bit | 170.4 x 127.8 | 80 / 80 / 80 / 60 | 600 | 450 | -30º~85º | No |
|
| 10.1" | 1280*1200 | USMP-T101-192120NDU-A0 | LVDS | 217.44 x 135.9 | 85 / 85 / 85 / 85 | 800 | 800 | -30º~85º | No |
|
| 10.1" | 1024*600 | USMP-T101-102060NAS-A0 | LVDS | 222.72 x 125.28 | 80 / 80 / 80 / 80 | 500 | 500 | -30º~85º | No |
|
| 10.4" | 800*600 | USMP-T104-080060NCJ-A0 | 6bit LVDS | 211.2 x 158.4 | 70 / 70 / 50 / 60 | 500 | 500 | -30º~80º | No |
|
| 10.4" | 1024*768 | USMP-T104-102076NDU-A0 | 20-pin LVDS | 211.2 x 158.4 | 60 / 70 / 75 / 75 | 800 | 1200 | -20º~70º | No |
|
| 10.4" | 640*480 | USMP-T104-064048NDN-A0 | 1 ch TTL | 211.2 x 158.4 | 80 / 80 / 60 / 70 | 700 | 400 | -20º~80º | No |
|
| 10.4" | 800*600 | USMP-T104-080060NDU-A0 | 20-pin LVDS | 211.2 x 158.4 | 60 / 80 / 80 / 80 | 800 | 1500 | -30º~80º | No |
|
| 12.1" | 800*600 | USMP-T121-010076NAF-A0 | LVDS | 245.76 x 184.32 | 70 / 70 / 80 / 80 | 700 | 600 | -30º~80º | No |
|
| 12.1" | 800*600 | USMP-T121-080060NDN-A0 | 8-bit | 246 x 184.5 | 80 / 80 / 65 / 75 | 700 | 450 | -30º~85º | No |
|
| 12.3" | 1920*720 | USMP-T123-192072NBQ-A0 | LVDS | 292.608 x 109.728 | 85 / 85 / 85 / 85 | 1000 | 750 | -30 ~ 85° | No |
|
| 12.3" | 1920*720 | USMP-T123-192072NDV-A0 | LVDS | 292.023 x 109.512 | 85 / 85 / 85 / 85 | 1000 | 700 | -30 ~ 80° | No |
|
| 12.3" | 1920*720 | USMP-T123-192072CDV-A2 | LVDS | 292.032 x 109.512 | 85 / 85 / 85 / 85 | 1000 | 1000 | -30°~80° | CTP |
|
| 19" | 1280*1024 | USMP-T190-128102NDN-A0 | 2 ch LVDS | 376.32 x 301.056 | 89 / 89 / 89 / 89 | 2000 | 600 | 0 ~ 50° | No |
|
| 22" | 1680*1050 | USMP-T220-168105NDN-A0 | 2 ch LVDS | 473.76 x 296.1 | 89 / 89 / 89 / 89 | 2000 | 250 | 0º~50º | No |
|
| 23" | 1920 x 1080 | USMP-M230HGE-P20 | 2 ch LVDS | 509.184 x 286.416 | 85 / 85 / 85 / 85 | 1000 | 0°~50° | No |
|
|
| 27" | 1920*1080 | USMP-T27-192108MEH-TBD | VGA/DVI-D/HDMI | 597.6 x 336.15 | 89 / 89 / 89 / 89 | 1000 | 1700 | -30º~80º | Yes |
|
| 28" | 3480*2160 | USMP-T280-384216NBQ-A0 | 51 pins 8 lane –V by 1 | 620.93 x 341.28 | 80 / 80 / 85 / 85 | 1000 | 300 | 0º~50º | No |
|
| 50" | 3840*2160 | USMP-T500-384216NBQ-A0 | 8 lane V by 1 | 1095.84 x 616.41 | 88 / 88 / 88 / 88 | 4000 | 500 | 0º~50º | No |
|
Open Frame Monitor Products
| Panel Size | Part Number | Resolution | Active Size | Brightness | Display Colors | Operating Temp. | Pixel Pitch | Viewing Angle | Datasheet |
|---|---|---|---|---|---|---|---|---|---|
| 7" | USMP-F070-102060RBZ-A0 | 1024 x 600 | 156.6 x 90 | 400 | 16.7M | -30º~85º | 0.150 x 0.150 | 75º / 75º / 75º / 75º |
|
| 9.7" | USMP-F097-102076CBZ-A0 | 1024 x 768 | 196.61 x 147.46 | 260 | 16.2M | 0º~50º | 0.192 x 0.192 | 85º / 85º / 85º / 85º |
|
| 10.1" | USMP-F101-128080CBZ-A0 | 1280 x 800 | 216.96 x 135.60 | 300 | 16.2M | -20º~60º | 0.1695 x 0.1695 | 85º / 85º / 85º / 85º |
|
| 10.4" | USMP-F104-102076CBZ-A0 | 1024 x 768 | 211.2 x 158.4 | 350 | 16.7M/262K | 0º~50º | 0.2055 x 0.2055 | 85º / 85º / 85º / 85º |
|
| 12.1" | USMP-F121-102076CBZ-A0 | 1024 x 768 | 245.76 x 184.32 | 350 | 16.7M | -20º~70º | 0.24 x 0.24 | 80º / 80º / 80º / 80º |
|
| 14" | USMP-F140-192108CBZ-A0 | 1920 x 1080 | 309.312 x 173.988 | 250 | 262K | 0º~50º | 0.264 x 0.264 | 85º / 85º / 85º / 85º |
|
| 14" | USMP-F140-192108CBZ-B0 | 1920 x 1080 | 309.312 x 173.988 | 250 | 262k | 0º~50º | 0.1611 x 0.1611 | 85º / 85º / 85º / 85º |
|
| 15" | USMP-F150-102076RBZ-A0 | 1024 x 768 | 304.128 x 228.096 | 300 | 16.2M/262k | -10º~70º | 0.297 x 0.297 | 89º / 89º / 89º / 89º |
|
| 15" | USMP-F150-102076RBZ-B0 | 1024 x 768 | 304.128 x 228.096 | 250 | 262k | -10º~70º | 0.297 x 0.297 | 50º / 50º / 60º / 60º |
|
| 15" | USMP-F150-102076CBZ-A0 | 1024 x 768 | 304.128 x 228.096 | 250 | 16.2M/262k | -20º~70º | 0.297 x 0.297 | 80º / 80º / 70º / 70º |
|
| 15.6" | USMP-F156-192108CBZ-A0 | 1920 x 1080 | 344.16 x 193.59 | 350 | 16.7M | -10º~70º | 0.17925 x 0.17925 | 60º / 60º / 70º / 70º |
|
| 17" | USMP-F170-128102CBZ-C0 | 1280 x 1024 | 337.920 x 270.336 | 350 | 16.7M | -0º~50º | 0.264 x 0.264 | 85º / 85º / 80º / 80º |
|
| 17" | USMP-F170-128102RBZ-A0 | 1280 x 1084 | 337.92 x 270.33 | 250 | 16.7M | 0º~70º | 0.24 x 0.24 | 80º / 80º / 85º / 85º |
|
| 17" | USMP-F170-128102CBZ-A0 | 1280 x 1024 | 337.920 x 270.336 | 250 | 16.7M | -20º~60º | 0.264 x 0.264 | 85º / 85º / 80º / 80º |
|
| 17" | USMP-F170-128102CBZ-B0 | 1280 x 1024 | 337.920 x 270.336 | 350 | 16.7M | -20º~60º | 0.264 x 0.264 | 85º / 85º / 80º / 80º |
|
| 18.5" | USMP-F185-192108CBZ-A0 | 1920 x 1080 | 408.96 x 230.04 | 350 | 16.7M | -20º~70º | 0.213 x 0.213 | 89º / 89º / 89º / 89º |
|
| 19" | USMP-F190-128102CBZ-A0 | 1280 x 1024 | 376.32 x 301.06 | 250 | 16.7M | -20º~50º | 0.264 x 0.264 | 85º / 85º / 80º / 80º |
|
| 21.5" | USMP-F215-192108CBZ-D0 | 1920 x 1080 | 476.064 x 267.786 | 250 | 16.7M | 0º~50º | 0.24825 x 0.24825 | 89º / 89º / 89º / 89º |
|
| 21.5" | USMP-F215-192108CBZ-A0 | 1920 x 1080 | 476.64 x 268.116 | 250 | 16.7M | 0º~50º | 0.24825 x 0.24825 | 89º / 89º / 89º / 89º |
|
| 21.5" | USMP-F215-192108CBZ-B0 | 1920 x 1080 | 476.64 x 268.116 | 250 | 16.7M | 0º~50º | 0.24825 x 0.24825 | 89º / 89º / 89º / 89º |
|
| 21.5" | USMP-F215-192108CBZ-C0 | 1920 x 1080 | 476.064 x 267.786 | 450 | 16.7M | 0º~50º | 0.24795 x 0.24795 | 89º / 89º / 89º / 89º |
|
| 31.5" | USMP-F315-192108CBZ-A0 | 1920 x 1080 | 698.4 x 392.85 | 300 | 16.7M | 0º~50º | 0.12125 x 0.12125 | 89º / 89º / 89º / 89º |
|
| 32" | USMP-F320-192108CBZ-A0 | 1920 x 1080 | 698.4 x 392.85 | 300 | 16.7M | 0º~50º | 0.12125 x 0.12125 | 89º / 89º / 89º / 89º |
|
| 43" | USMP-F430-192108CBZ-A0 | 1920 x 1080 | AMG-43IPAM01T1-en | 300 | 16.7M | 0º~50º | 89º / 89º / 89º / 89º |
|
Casino floors are loud and noisy, full of sparkling lights and distractions. Gaming companies are constantly evolving to find a way to differentiate their slot machines from their competitors.
Mechanical spinning reels are a thing of the past. Little by little, different components of the slot machines are being replaced by displays. From LED arrays and small monochromatic displays to 80” 4K displays, slot machines are rapidly changing.
Where to Start?
These are the required features to make your slot machine stand out from the crowd:
| OPTIONAL FEATURES: | |
|---|---|
| High image quality (high resolution and high contrast) | Privacy film |
| High color gamut | Certification required |
| High brightness (500 nits or more) | Extended product longevity |
| Wide view angles | Low cost solutions available) |
| Quick response time | |
| High refresh rate to prevent lag | |
| Low power consumption | |
| Long display lifetime |
| TECHNOLOGIES FOR GAMING | PMOLED |
|---|
| AMOLED |
| UHD 4k |
| 3D |
| Multi-layer Display |
APPLICATIONS
Slot Machines
Our OLED displays are used in slot machines worldwide. Their robust design provides years of usage in this high traffic, extreme environment application. From their buttons to their main panels, USMP has provided solutions to the biggest names in the Gaming market.
Handheld Poker Device
Our white monochrome PMOLED perfects this handheld poker device. The high contrast of the white on true black background along with the wide viewing angles makes these extremely visible from all locations on the poker table and an ideal fit for this application.
Our Display Engineers will analyze your requirements and design the best solution for your specific application. Once we design a solution, we will manufacture, do quality control and deliver a high quality display at the best value. To find out more about our Engineered Display Solutions Process, visit our Custom Displays page.
